Petrochemical equipment series products




Automatic ignition system

The combustion control of single or multiple burners, equipped withignition device, flame monitoring device, fuel control, air flow control systemfor each burner, and equipped with local control cabin

Hotline:

+86 0730-8752158

  • Product details

The combustion control of single or multiple burners, equipped withignition device, flame monitoring device, fuel control, air flow control systemfor each burner, and equipped with local control cabinet (PLC system), localfire tray, etc., can achieve local or remote automatic ignition control, andeffective monitoring during the combustion process, which can achieve manualadjustment or automatic P&ID adjustment control of burner flame size (power).



Ignition device

The ignition device generally consists of an igniter, ignition gun(ignition rod), ignition cable, etc. According to the equipment method, it canbe divided into fixed igniters and portable igniters. Igniters can also bedivided into high-energy igniters and high-pressure (with high-pressurepackage) igniters, which need to be selected appropriately according to therequirements of burner control.



ZDQ-20 series high-energy igniter

This product is a low-voltage high-energy discharge system forcapacitive energy storage, equipped with ignition cables and semiconductorignition rods to form a high-energy ignition device. Can be used to directlyignite air/vapor atomized oil mist such as natural gas, liquefied petroleumgas, diesel, heavy oil, etc. It has the characteristics of high output ignitionenergy, strong resistance to pollution and humidity, strong anti cokingability, compact structure, and safety and reliability, and its performance issignificantly better than the high-voltage gap ignition method.



Technical parameters of ZDQ-20 series high-energy igniter



Item

Parameter

Energy Storage

20J

Input Voltage

220V±10%z

Output Voltage

2200V/DC

Spark Frequency

4-18Hz

Working Current

≤3A

Working Cycle

30s/60s (working/intermittent)

Ambient Temperature

≤65

Relative Humidity

≤85%

Model

ZDQ-20/ZDQ-20Ex



ZDQ-20Ex series portable high-energy igniter

The ZDQ-20Ex series igniter is a capacitor energy storage low-voltagehigh-energy discharge system, equipped with ignition cables and semiconductorignition rods to form a high-energy ignition device. Can be used to directlyignite air/vapor atomized oil mist such as natural gas, liquefied petroleumgas, diesel, heavy oil, etc. It has the characteristics of high output ignitionenergy, strong resistance to pollution and humidity, strong anti cokingability, compact structure, and safety and reliability, and its performance issignificantly better than the high-voltage gap ignition method





Technical parameters of ZDQ-05 series portable high-energy igniter

Item

Parameter

Energy Storage

5J

Input Voltage

12V±10% DC

Output Voltage

2200V/DC

Spark Frequency

4-18Hz

Working Current

≤3A

Charger power

5W

Working Cycle

30s/60s (working/intermittent)

Ambient Temperature

≤65

Relative Humidity

≤85%

Model

ZDQ-05A/ZDQ-05B
